WhatsApp Analyst

A WhatsApp bot that answers dataset questions via Luzmo’s hosted /AIPrompt API (agent: analyst), replies with WhatsApp-formatted text, and uploads chart PNGs when Luzmo returns a visualization.

Synthetic/demo data and a phone allowlist only — not production identity linking.

Policy notes

WhatsApp Business Solution Terms restrict AI providers when AI is the primary functionality (Meta decides). Prefer demo recipients with EEA or Brazil country codes, or obtain written legal/Meta clearance for other regions (e.g. UK +44). Do not treat a non-EEA demo as policy-cleared without that clearance.

WhatsApp Business Solution Data must not train shared AI models. Confirm Luzmo’s Trust Center posture before any customer-data use. Keep the bot dataset-specific; refuse clearly off-topic / general-purpose prompts.

Prerequisites

• Node.js 22+ (uses built-in node:sqlite)
• Luzmo org with IQ addon and Organization Owner API key/token (required to mint embed authorizations)
• One demo dataset with a tenant column and distinct values for two personas
• Meta developer app + WhatsApp test number
• Public HTTPS tunnel (ngrok / Cloudflare Tunnel)
• Two WhatsApp phones as Meta test recipients

Setup

npm install
cp .env.example .env
cp config/allowlist.example.json config/allowlist.json
# Edit .env and allowlist.json with real values / demo phones

.env and config/allowlist.json are gitignored — never commit secrets or real phone numbers.

Environment

WHATSAPP_WABA_ID is not required at runtime.

Meta webhook

1. Tunnel: ngrok http 3000 or cloudflared tunnel --url http://localhost:3000.
2. Set PUBLIC_BASE_URL to the tunnel HTTPS origin.
3. Callback URL: https://<tunnel>/webhooks/whatsapp.
4. Verify token = WHATSAPP_VERIFY_TOKEN.
5. Subscribe to messages.
6. Add demo phones as test recipients in Meta API Setup.

Run

npm run verify-config
npm run dev
# or
npm run build && npm start

Health: GET /healthz

Smoke scripts

npm run smoke:meta -- 32470000001
npm run smoke:luzmo -- "What is total revenue?"
npm run themes:list

Demo script

1. Show shared dataset + tenant column.
2. Show allowlist personas and tenant values.
3. Phone A: What is total revenue? Show me a chart.
4. Phone B: same question → different numbers/chart.
5. Phone A follow-up: Break that down by month.
6. /reset, then a pronoun-only follow-up loses context.

Architecture

WhatsApp -> signed webhook -> persist/dedupe by wamid -> 200
  -> per-identity serial queue
  -> allowlist persona
  -> mint embed (dataset + tenant filter)
  -> /aiprompt SSE (buffer to completion)
  -> WhatsApp text (+ PNG via Media API using SAME embed token)

• Chart export uses the same Embed key/token as /AIPrompt (never owner credentials).
• Optional LUZMO_THEME_ID is applied only on PNG export.
• Luzmo conversation idle TTL: 60 minutes (separate from Meta’s 24h service window).
• Storage: Node node:sqlite (experimental flag on npm start / npm run dev).

Tests

npm test

Reference

See createAIPrompt.md. Sibling pattern: the Luzmo Analyst Slackbot in this repository.
